stainless steel 304 Glass door upper patch fitting office door and shop

stainless steel 304 Glass door upper patch fitting office door and shop

Product Description

*Note:

This product is made of non-ferrous metals. Refusing to use all acid and alkali products for cleaning, otherwise it will cause corrosion

of the product surface (Reminder: regular maintenance is recommended)The normal range of opening and closing doors of our products

is 80,000 times. (The use of violent switches and sliding doors is prohibited)

Installation and adjustment of glass door clamp

1. Positioning and setting out

The fixed glass and movable glass door leaf are used to combine the glass door, and the setting out and positioning are carried out uniformly. According to the requirements of the design and construction drawings, the positioning line of the glass door is set out, and the position of the door frame is determined at the same time.

1. Top limit slot of mounting frame

The width of the limit groove shall be 2 to 4 mm greater than the thickness of the glass, and the groove depth shall be 10 to 20 mm.

During installation, at first, two metal decorative panel sidelines are led out from the snapped Zhongfan line, then the limit groove on the top of the door frame is installed according to the sideline, and the groove depth in the notch is adjusted by gluing the base plate.

1. Install metal finished wooden bottom support

Fix the square wood on the ground, and glue the metal decorative panel to the wood with universal glue. If aluminum alloy square pipe is used, it can be fixed on the frame column with aluminum angle, or on the wooden brick buried in the ground with wood screws.

1. Install vertical door frame

Nail the square timber of the door frame with the snapped center line, then use plywood to determine the shape and position of the door frame column, and finally wrap the metal decorative surface. When wrapping the veneer, place the butt joint of the veneer at the middle door on both sides of the glass installation.

1. Install glass

Use a glass suction cup machine to suck the thick glass tightly, and lift the thick glass plate to the installation position. First insert the upper part of the glass into the limit slot on the top of the door frame, and then put the lower part of the glass on the bottom bracket.

1. Fixed glass

Nail two small square wood strips inside and outside the square wood on the bottom support, clamp the thick glass on the middle door, paint the square wood strip with all-purpose glue, and stick the facing metal on the square wood strip.

1. Glass sealant sealing

Inject glass glue into the two sides of the top limit groove and the bottom bracket opening, as well as the joints between the thick glass and the frame column, and then scrape off the excess glass glue with tools.

1. Glass butt joint

When the fixed part of the glass door needs to be spliced due to its large size, the butt joint should have a width of two to three millimeters, and the edge of the glass plate should be chamfered.

1. Installation of ground spring

Before installing the door leaf, the ground spring and the locating pin on the top surface of the door frame should be installed and must be coaxial. During installation, it is best to check with a hanging plumb line to ensure that they are in the same line.

1. Install the upper and lower door clips

Install the upper and lower metal door clamps on the upper and lower ends of the glass door leaf respectively. If the height of the door leaf is not enough, wood plywood strips can be padded at the bottom of the glass in the lower door clamp.

1. Fix the glass door clip

After setting the height of the door leaf, insert small wooden strips into the gaps between the glass and the upper and lower door clips, and inject glass glue into the gaps for fixation.

1. Door leaf installation

First, pull the positioning pin out of the beam plane by 2mm with its own adjusting screw, erect the office glass door leaf, align the hole position of the rotating pin connector in the door clamp under the door leaf with the rotating pin shaft of the ground spring, rotate the door leaf to put the hole position on the pin shaft, rotate the door leaf to form a right angle with the door frame beam, align the hole of the rotating connector in the door clamp of the door leaf with the positioning pin on the door frame beam, and adjust the adjusting screw of the positioning pin, Insert the locating pin into the hole.

1. Handle installation

Before installation, apply a little glass glue on the part where the handle is inserted into the glass. When the handle is assembled, the root is close to the glass, and then press the fixing screw tightly to ensure that the handle is not loose.
